Picture of Standalone Controller 8ch

Standalone Controller 8ch

  • Range :
    Projectors
  • Code :
    STANDALONE-CONTROLLER
  • Description :
    Technical Specifications:
    • Cover Material: Iron
    • Operating temperature :-15°C ~ +60°C
    • Humidity: ≤50% RH
    • Power consumption :<3W
    • Environment: IP20
    • Cascade signal: Optocoupler
    • Master controller signal: Ethernet protocol
    • Network interface: RJ45 Ethernet interface
    • Output signal: TTL & RS-485 × 8 channels
    • Control capacity: Up to 154 Sub-controllers or 4,00,000 channels
    • Transmission distance: Use UTP (unshielded twisted pair) cable, distance between the controllers can be
    • Weight: 2050 gm
    • Dimension: 285mm (L) × 156mm (W) × 45mm (H)
    • Pixel driven: Single chip: 960 pixels × 8 channels; Single-wire: 1024 pixels × 8 channels; Standard DMX512: 168 pixels × 8 channels; Extensible DMX: 336 pixels × 8 channels; Break-point resume: 960 pixels × 8 channels
